L-shaped Trim
Deliver a clean, minimalist edge termination and reliable structural defense with WINSEN L-shaped Trim, the versatile architectural angle profile engineered to seal and finish exposed tile boundaries.
Technical Data Sheet
- Raw Material：6063/6463 Aluminum Alloy
- Certifications：ISO9001, CE, RoHS
- Shape：L shape, Round edge, T shape, Square edge or Customized
- Length：0.9/1.0/2.4/2.5/2.6/2.7/2.8/3.0/ Customized
- Height：7mm/8mm/9mm/10mm/11mm/12mm/13mm/14mm/ Customized
- Thickness：0.5-1.5mm/ Customize
- Color：Silver/ Gold/ Champagne/ Rose Gold/ Bronze/ Black/ White/ Customized
- Punching Hole：Round/ trapezoid/ triangle/ regular triangle/ square/ Customized
- Surface Treatment：Anodize, Polish, Matt, Brushed, Powder Coating, Wood Grain, etc.
Application
Surface & Colors
Surface treatment and colors can be customized.
Punching Hole
Customize anchoring hole patterns, dimensions, and positioning for optimal thin-set mortar bonding.
Available in standard and specialty punches (round, square, slot).
Package
Capability
OEM&ODM
Flexible production for distributors, contractors, and private-label programs.
Precision extrusion & molds
3000+ extrusion dies support fast profile matching, new section development, and repeat production.
DWG→DIE→FIRST ARTICLE
Batch-controlled finishes
Anodizing and powder-coating controls keep color and surface treament aligned across repeat shipments.
LAB SAMPLE→MASTER CHIP→BATCH
Punching, labeling & packing
Round, slot, or square mounting holes, branded protective film, and barcoded export cartons.
PUNCH→FILM→PRIVATE LABEL
Any questions?
We’re Here to Help.
Explore answers to the most common inquiries, carefully curated to save you time and guide your decisions.
Need further assistance? Our team is just a message away.
Q1: How to fix uneven or chipped tile edges around a shower?
A: The best professional method is to retrofit an L-shaped metal tile trim over the damaged boundary. If the tiles are already set, you can use a retrofit L-angle trim and bond it cleanly over the exposed corner using a high-quality, moisture-resistant polyurethane construction adhesive. This immediately conceals the jagged ceramic edges and provides a clean, watertight architectural finish.
Q2: How to cut L shaped aluminum trim corners cleanly?
A: Use a precision miter saw equipped with a non-ferrous carbide-tipped blade (80+ teeth) and clamp the trim firmly against a backing block. Cut at a 45-degree angle with a slow, steady downward motion to prevent the thin metal lip from burring, twisting, or heating up. Always use a fine metal file to deburr the freshly cut edges before embedding them in mortar to ensure a perfectly flush joint.
Q3: What L-shaped trim matches KOHLER brushed brass fixtures?
A: To match KOHLER “Vibrant Brushed Moderne Brass” fixtures, the closest architectural equivalent is a bright brushed gold 3/8 in aluminum L-shaped trim. KOHLER’s brass finish features a warm, subtly muted golden tone with fine brush strokes. A high-quality anodized brushed gold aluminum profile provides a near-perfect complementary finish that, unlike raw brass, will never tarnish, oxidize, or turn green in a humid shower environment.
Q4: Where is a 10mm matte black L shape tile edging profile best applied?
A: It is best applied as a minimalist, high-contrast border for shower niches, external wall corners, and modern backsplashes utilizing standard 8mm to 9mm thick tiles. The durable matte anodized finish absorbs light, completely hiding water spots, and frames light-colored ceramic or marble to create a striking contemporary aesthetic.
Q5: When should you use a stainless steel L angle tile transition strip 1/2 inch?
A: You should use a stainless steel L angle tile transition strip 1/2 inch when bridging thick, heavy-duty floor materials like natural stone, terrazzo, or large-format porcelain in high-traffic commercial zones. The 1/2-inch (approx. 12.5mm) depth easily accommodates thicker floor coverings, while the rigid Grade 304 or 316 stainless steel construction delivers extreme structural durability and superior resistance to corrosive chemical floor cleaners.
Need a Custom Profile?
Don’t see the exact dimension or finish your project requires?
We specialize in full OEM & ODM manufacturing. Submit your specifications or customization demand, let our in-house engineering team bring your exact blueprint to life.
